Περιγραφή
Design
Mounting type: Ceiling/wall
Housing material: Plastic, Metal
Form factor: Turret
Built-in microphone: Yes
International Protection (IP) code: IP67
Product colour: White
Power
DC output current: 0.4 A
Power source type: DC, PoE
Power consumption (Power over Ethernet (PoE)): 6.5 W
Power consumption (max): 5 W
DC output voltage: 12
Security
Video motion detection: Yes
Password protection: Yes
Mirror: Yes
Digital watermark: Yes
Heartbeat: Yes
Operational conditions
Storage temperature (T-T): -30 - 60 °C
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Web-based management: Yes
Dedicated application: Hik-Connect (Android, iOS)
Weight & dimensions
Package width: 150 mm
Package height: 141 mm
Diameter: 11 cm
Package depth: 150 mm
Package weight: 560 g
Height: 89.2 mm
Weight: 340 g
Network
Bluetooth: No
Ethernet LAN: Yes
Number of users: 32 user(s)
Networking standards: IEEE 802.3af
Quality of Service (QoS) support: Yes
Wi-Fi: No
Performance
Day/night mode: Yes
Type: IP security camera
Infrared (IR) cut-off filter: Yes
Placement supported: Outdoor
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Pan range: 0 - 360°
Camera tilt control: Yes
Angle of rotation: 360°
Viewing angle, vertical: 54°
Camera shutter speed: 1/3 - 1/100000 s
Viewing angle, horizontal: 98°
Viewing angle, diagonal: 114°
Camera pan control: Yes
Tilt angle range: 0 - 75°
Image sensor
Sensor type: CMOS
Optical sensor size: 25.4 / 3 mm (1 / 3")
Progressive scan: Yes
Number of sensors: 1
Video
Supported graphics resolutions: 2560 x 1440, 640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 640 x 480 (VGA)
Video compression formats: H.264, H.264+, H.265+, M-JPEG, H.265
Image quality adjustment: Saturation, Brightness, White balance, Contrast, Sharpness
Privacy masking: Yes
Gain control type: Auto
Frame rate: 20 fps
Total megapixels: 4 MP
Region of Interest (ROI) encoding: Yes
Video streaming: Yes
Maximum resolution: 2560 x 1440 pixels
Noise reduction technology: 3D noise reduction
Noise reduction: Yes
Bit rate: 32 Kbps - 8 Mbps
Night vision
Infra-red wavelength: 850 nm
Night vision distance: 30 m
LED type: IR
Night vision: Yes
Lens system
Maximum aperture number: 1.6
Fixed focal length: 2.8 mm
Number of lenses: 1
Warranty: warranty 36 months
