Περιγραφή
Technical details
Lens mount interface: M12
Iris: Yes
Design
Product colour: White
Form factor: Dome
Housing material: Metal, Plastic
IK code: IK08
International Protection (IP) code: IP67
Mounting type: Ceiling
Weatherproof: Yes
Power
Power consumption (max): 6 W
Power source type: DC, PoE
DC output current: 0.5 A
Power consumption (Power over Ethernet (PoE)): 7.5 W
DC output voltage: 12
Security
Password reset via email: Yes
Mirror: Yes
Active tampering alarm: Yes
Password protection: Yes
Digital watermark: Yes
Video motion detection: Yes
Heartbeat: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Management features
Web-based management: Yes
Weight & dimensions
Weight: 550 g
Height: 97.6 mm
Diameter: 12.2 cm
Network
Bluetooth: No
Quality of Service (QoS) support: Yes
User access level: Administrator, Operator, User
Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
Wi-Fi: No
Number of simultaneous live view channels: 6 channels
Ethernet LAN: Yes
Client interoperability: iVMS-4200, Hik-Connect
Live view: Yes
Number of users: 32 user(s)
Performance
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Day/night mode: Yes
Number of languages: 2
Dynamic range: 120 dB
Packaging data
Package width: 150 mm
Package weight: 800 g
Package depth: 150 mm
Package height: 141 mm
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Audio formats supported: AAC-LC, G.711 A-law, PCM, G.722.1, G.726, MP2L2
Sample rates: 8 - 16 kHz
Signal-to-Noise Ratio (SNR): 52 dB
Bit rate range: 16 - 160 Kbit/s
Storage
Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
Card reader integrated: Yes
Maximum memory card size: 512 GB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 75°
Angle of rotation: 355°
Lens viewing angle, horizontal: 113°
Lens viewing angle, diagonal: 134°
Lens viewing angle, vertical: 62°
Minimum illumination: 0 lx
Pan range: 0 - 355°
Camera shutter speed: 1/3 - 1/100000 s
Image sensor
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Video
Supported graphics resolutions: 640 x 360, 1920 x 1080 (HD 1080), 3860 x 2160, 3200 x 1800, 1280 x 720 (HD 720), 2688 x 1512, 640 x 480 (VGA)
Maximum resolution: 3840 x 2160 pixels
Bit rate: 32 Kbps - 16 Mbps
Total megapixels: 8 MP
Frame rate: 15 fps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Image quality adjustment: Contrast, White balance, Brightness, Saturation, Sharpness
Video compression formats: H.264+, H.265, M-JPEG, H.265+, H.264
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction: Yes
Privacy masking: Yes
Noise reduction technology: 3D noise reduction
Region of Interest (ROI) encoding: Yes
Video recording: Yes
Night vision
LED type: IR
Night vision distance: 30 m
Night vision: Yes
Infra-red wavelength: 850 nm
Lens system
Maximum aperture number: 2
Fixed focal length: 2.8 mm
Detect distance: 79 m
Number of lenses: 1
Identify distance: 7 m
Observe distance: 31 m
Recognize distance: 15 m
Sustainability
Compliance certificates: WEEE, Federal Communications Commission (FCC), RoHS, REACH, CB, Low Voltage Directive (LVD), KC
Warranty: Manufacturer warranty 24 months
