Περιγραφή
Design
Housing material: Plastic, Metal
Protection features: Waterproof
International Protection (IP) code: IP67
Product colour: White
Form factor: Bullet
Mounting type: Ceiling/wall
Power
Power consumption (max): 5 W
Power source type: DC, PoE
DC output voltage: 12
Power consumption (Power over Ethernet (PoE)): 6.5 W
DC output current: 0.41 A
Security
Privacy protection: Yes
Digest authentication: Yes
Audit log: Yes
Password protection: Yes
Heartbeat: Yes
Password reset via email: Yes
Digital watermark: Yes
Video motion detection: Yes
Mirror: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -30 - 60 °C
Management features
Web-based management: Yes
Weight & dimensions
Height: 69.1 mm
Weight: 285 g
Width: 66 mm
Length: 170.8 mm
Network
Bluetooth: No
Wi-Fi: No
Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Client interoperability: iVMS-4200, Hik-Connect
Number of users: 32 user(s)
Live view: Yes
Number of simultaneous live view channels: 6 channels
User access level: Administrator, Operator, User
Performance
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Built-in light: Yes
Number of languages: 1
Languages support: Polish
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Placement supported: Indoor & outdoor
Dynamic range: 120 dB
Packaging data
Package weight: 481 g
Package height: 118 mm
Package depth: 121 mm
Package width: 216 mm
Packaging content
Number of cameras: 1
Audio
Audio formats supported: G.722.1, G.726, AAC-LC, G.711, MP2L2, PCM
Built-in microphone: Yes
Signal-to-Noise Ratio (SNR): 52 dB
Sample rates: 8 - 16 kHz
Bit rate range: 16 - 160 Kbit/s
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Camera shutter speed: 1 - 1/100000 s
Pan range: 0 - 360°
Tilt angle range: 0 - 90°
Angle of rotation: 360°
Minimum illumination: 0 lx
Number of Privacy masking areas: 4
Lens viewing angle, diagonal: 127°
Lens viewing angle, horizontal: 105°
Lens viewing angle, vertical: 55°
Image sensor
Progressive scan: Yes
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Sensor type: CMOS
Number of sensors: 1
Video
Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080), 3200 x 1800, 1280 x 720 (HD 720), 2688 x 1520, 640 x 360
Maximum resolution: 3200 x 1800 pixels
Total megapixels: 6 MP
Highlight Compensation (HLC): Yes
Back Light Compensation (BLC): Yes
Bit rate: 32 Kbps - 16 Mbps
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video compression formats: M-JPEG, H.264+, H.264, H.265, H.265+
Image quality adjustment: Contrast, Saturation, Brightness, Sharpness, White balance
Region of Interest (ROI) encoding: Yes
Video streaming: Yes
Privacy masking: Yes
Night vision
Night vision distance: 30 m
Infra-red wavelength: 850 nm
Night vision: Yes
Lens system
Fixed focus: Yes
Fixed focal length: 2.8 mm
Detect distance: 76 m
Identify distance: 7 m
Number of lenses: 1
Maximum aperture number: 1.6
Recognize distance: 15 m
Observe distance: 30 m
Sustainability
Compliance certificates: RoHS, CE, REACH, WEEE, RCM, CB, Low Voltage Directive (LVD)
Sustainability compliance: Yes
Warranty: Manufacturer warranty 36 months
