Περιγραφή
Our patch cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
AWG: 22/1 (solid)
Specification: CAT 7A
Cable sheath diameter (approx.): 7.8 mm
width of cable sheath: 16.4 mm
height of cable sheath: 7.8 mm
inner conductor, core diameter: 0.615 mm
Shielding class: S/FTP (PiMF)
Number of shieldings: 2 x
Markings: DCA_CPR, CE, PoE
Impedance: 100 Ω
max. bandwidth: 1200 MHz
usable up to cable length: 90 m
Cable type: round cable
Material cable sheath: LSZH
Inner conductor material: CU (copper)
LSZH compliant: yes
Type 1, shielding: foil (alu) PiMF
Type 2, shielding: braid (alu) overall shield
Color: blue
Outer sheath material: LSZH
Fire class (CPR): Dca
Cable length: 50 m
Meter scaling: yes
Color version: blue
Consumption Unit: 1 pc. coil
