Περιγραφή
Our CAT cables transmit signals in top quality at high speed, always guaranteeing a stable connection. High-quality inner conductors, robust cable sheathing and precisely fitting plugs distinguish our portfolio of connection cables and plugs. Goobay always provides the perfect products for your network needs - whether you aim to set up a home or company network. Simply. All. You need!
AWG: 27/7 (stranded)
Specification: CAT 6
Cable sheath diameter (approx.): 5.8 mm
Shielding class: S/FTP (PiMF)
Number of shieldings: 2 x
Contacting: EIA/TIA-568 B
Markings: WEEE, CE
Operating temperature up to: 75 °C
Operating temperature from: -20 °C
max. bandwidth: 250 MHz
Kink protection: both sides
Cable type: round cable
Material cable sheath: LSZH
Inner conductor material: CU (copper)
LSZH compliant: yes
Type 1, shielding: foil (alu) PiMF
Type 2, shielding: braid (alu) overall shield
Connection, contact material: gold-plated 3um
Connection, shielding: yes
Connection, type: RJ45 female (8P8C)
Connection 2, type: RJ45 male (8P8C)
Latch protection: unilaterally
Color: black
Special feature: Length indication on connector
Cable length: 0.5 m
Max. resolution: 10K/30Hz (10240x4320)
Color version: black
Outer sheath material: LSZH
