Gigabyte UD1000GM PG5 power supply unit 1000 W 20+4 pin ATX ATX Black - (GP-UD1000GM PG5 Rev 2.0)

Design
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black

Power
Efficiency: 90%
Hold time: 16 ms
Power protection features: Over power, Short circuit, Over voltage, Under voltage, Over current
Input current: 6.5 - 15 A
Power Good signal delay range: 100 - 150 ms
Total power: 1000 W
Power Factor Correction (PFC) type: Active
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz

Weight & dimensions
Width: 150 mm
Height: 140 mm
Depth: 86 mm

Performance
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 100000 h
Bearing technology: HYB
Purpose: PC
80 PLUS certification: 80 PLUS Gold

Ports & interfaces
Peripheral (Molex) power cable length: 500 mm, 150, 120
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 150, 600 mm
CPU power cable length: 80 cm
ATX power connector (20+4 pin): Yes
PCI Express power connectors (6+2 pin): 4
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4-pin): 4
Number of SATA power connectors: 8
Motherboard power cable length: 61 cm
Cabling type: Modular
PCI Express power cable length: 70 cm
PCI Express power connectors (16-pin): 1


Warranty: warranty 120 months
