Περιγραφή
Processor
Compatible processor series: 3rd Generation AMD Ryzen(TM) 9, 3rd Generation AMD Ryzen(TM) 7, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen(TM) 3
Maximum number of SMP processors: 1
Processor manufacturer: AMD
Processor socket: Socket AM4
Graphics
Maximum graphics card memory: 16000 MB
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Features
Windows operating systems supported: Windows 10 x64
Motherboard chipset family: AMD
PC health monitoring: Fan, Voltage, Temperature
Motherboard chipset: AMD B550
Motherboard form factor: micro ATX
Memory
Supported memory clock speeds: 2400, 4000, 4600, 3200 MHz, 2667, 4400, 2933, 3600, 4733, 3333, 2133
Maximum internal memory: 128 GB
Number of memory slots: 4
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Internal I/O
Number of SATA III connectors: 4
12V power connector: Yes
CPU fan connector: Yes
RGB LED pin header: Yes
Front panel connector: Yes
Serial port headers: 1
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
Number of chassis fan connectors: 2
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: Serial ATA III
RAID levels: 0, 10, 1
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DVI-D ports quantity: 1
USB 2.0 ports quantity: 4
HDMI version: 2.1
HDMI ports quantity: 1
Expansion slots
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 slots: 2
Number of M.2 (M) slots: 2
Warranty: warranty 36 months
