Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 7000 Series
Processor manufacturer: AMD
Maximum internal memory supported by processor: 192 GB
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Features
PC health monitoring: Temperature, Voltage, Water cooling, Fan
Motherboard chipset: AMD A620
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Product colour: Bronze
Memory
Memory slots type: DIMM
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8000 MHz
Number of memory slots: 4
ECC ?ompatibility: Non-ECC
Supported memory clock speeds: 8000, 6400, 5600, 7200, 4400, 6000, 6800, 7600 MHz, 7800, 7000, 5200, 6200, 4800 MHz
Supported memory module capacities: 16GB, 1GB, 8GB, 48GB, 32GB, 12GB, 2GB, 4GB
Maximum internal memory: 192 GB
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
Front panel audio connector: Yes
TPM connector: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
USB 2.0 connectors: 1
Number of SATA III connectors: 4
RGB LED pin header: Yes
Total number of SATA connectors: 4
EPS power connector (8-pin): Yes
CPU fan connector: Yes
12V power connector: Yes
BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package weight: 892 g
Package width: 270 mm
Package depth: 268 mm
Package height: 68 mm
Packaging content
Cables included: SATA
Batteries included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
RAID levels: 0, 10, 1
Supported storage drive types: HDD & SSD
Number of storage drives supported: 5
Rear panel I/O ports
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Headphone outputs: 3
USB 2.0 ports quantity: 2
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.4
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Expansion slots
PCI Express x1 slots: 1
Number of M.2 (M) slots: 1
PCI Express x16 slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
Warranty: warranty 36 months
