Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM4
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 3000 Series
Maximum internal memory supported by processor: 64 GB
Supported processor sockets: Socket AM4
Graphics
Number of displays supported: 3
On-board graphics card: No
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 5120 x 2880 pixels
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Motherboard form factor: mini ITX
Audio output channels: 7.1 channels
Product colour: Black
Audio chip: Realtek ALC887
Motherboard chipset: AMD A520
PC health monitoring: Voltage, Fan, Temperature
Memory
Number of memory slots: 2
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR4-SDRAM
Supported memory clock speeds: 5100 MHz, 4000, 3200, 2667, 4400, 5000, 2933, 3600, 4600, 2400, 4866, 5200, 3333, 2133 MHz
Supported memory module capacities: 1GB, 8GB, 12GB, 32GB, 16GB, 2GB, 4GB
Maximum internal memory: 64 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 5300 MHz
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Height: 35 mm
Depth: 170 mm
Width: 170 mm
Network
Bluetooth version: 4.2
Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, 802.11a, 802.11b
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Bluetooth: Yes
Internal I/O
ATX Power connector (24-pin): Yes
Audio connector: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
Power fan connector: Yes
RGB LED pin header: Yes
Serial port headers: 1
Front panel connector: Yes
CPU fan connector: Yes
Total number of SATA connectors: 4
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
USB 2.0 connectors: 1
BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package width: 222 mm
Package depth: 189 mm
Package weight: 800 g
Package height: 78 mm
Packaging content
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
RAID levels: 1, 10, 0
Number of storage drives supported: 5
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 2.0 ports quantity: 2
WiFi-AP antenna jack: 2
Headphone outputs: 3
HDMI ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI version: 2.1
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 slots: 1
Battery
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Battery type: CR2032
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Dispose of according to local electro-waste regulations., Store away from water and sources of moisture., Avoid direct contact with sensitive electronic components.
Warranty: warranty 36 months
