Περιγραφή
Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Power source type: ATX
PC health monitoring: Temperature, Water cooling, Fan, Voltage
Motherboard form factor: ATX
Product colour: Bronze
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Memory
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speeds: 8000 MHz, 7800, 7000, 4800, 6200, 6800, 6400, 5600 MHz, 7200, 6000, 6600, 5200, 4400, 7600 MHz
Maximum internal memory: 256 GB
Number of memory slots: 4
Memory channels: Dual-channel
ECC ?ompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 8000 MHz
Weight & dimensions
Height: 35 mm
Depth: 244 mm
Width: 305 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b, 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8852CE
Wi-Fi: Yes
LAN controller: Realtek RTL8125
Bluetooth: Yes
Internal I/O
Front panel audio connector: Yes
Serial port headers: 1
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
Number of SATA III connectors: 4
RGB LED pin header: Yes
CPU fan connector: Yes
Front panel connector: Yes
12V power connector: Yes
Number of water pump connectors: 2
Number of chassis fan connectors: 3
USB 3.2 Gen 2x2 connectors: 1
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of RGB LED pin headers: 5
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 1
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package depth: 270 mm
Package width: 335 mm
Package weight: 2.16 kg
Package height: 80 mm
Packaging content
Batteries included: Yes
Screws included: Yes
Antenna included: Yes
Storage controllers
RAID levels: 10, 0, 1
Number of storage drives supported: 7
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
HDMI ports quantity: 1
DisplayPort version: 1.4
Microphone in: Yes
USB 2.0 ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Line-in: Yes
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
Headphone outputs: 1
Expansion slots
PCI Express x16 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 25110
3rd M.2 largest key size: 25110
3rd M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage.
Warranty: warranty 36 months
