Περιγραφή
Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
PC health monitoring: Voltage, Fan, Temperature
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Product colour: Bronze
Motherboard chipset: AMD B650
Power source type: ATX
Audio chip: Realtek ALC897
Cooling type: Passive
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Supported memory clock speed (max): 6400 MHz
Maximum internal memory per slot: 64 GB
ECC ?ompatibility: Non-ECC
Supported memory clock speeds: 6000, 4800, 4400, 6400, 5200, 5600 MHz, 6200
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Weight & dimensions
Depth: 225 mm
Height: 35 mm
Width: 230 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek RTL8111H
Wi-Fi: No
Internal I/O
RGB LED pin header: Yes
12V power connector: Yes
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
USB 2.0 connectors: 2
CPU fan connector: Yes
Number of chassis fan connectors: 2
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of RGB LED pin headers: 2
Front panel connector: Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging data
Package weight: 917 g
Package depth: 265 mm
Package width: 265 mm
Package height: 54 mm
Packaging content
Screws included: Yes
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 10, 0
Number of storage drives supported: 5
Rear panel I/O ports
Line-in: Yes
Headphone outputs: 1
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
PS/2 ports quantity: 1
Microphone in: Yes
HDMI version: 2.1
HDMI ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2580
Battery
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
Warranty: warranty 36 months
