Περιγραφή
Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Graphics
Maximum resolution: 4096 x 2304 pixels
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: AMD
Power source type: ATX
PC health monitoring: Water cooling, Fan, Voltage, Temperature
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Product colour: White
Motherboard chipset: AMD B650
Memory
Number of memory slots: 4
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Supported memory clock speed (max): 8000 MHz
Supported memory clock speeds: 8000, 5200, 6200, 6666, 5600 MHz, 7200, 6000, 6800, 4800, 4400, 6400, 7000, 7600, 7800, 6600
Maximum internal memory per slot: 64 GB
ECC ?ompatibility: Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8852CE
Wi-Fi: Yes
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Bluetooth: Yes
Internal I/O
Number of SATA III connectors: 4
Front panel connector: Yes
Front panel audio connector: Yes
12V power connector: Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
TPM connector: Yes
Number of chassis fan connectors: 4
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
Serial port headers: 1
Number of water pump connectors: 2
USB 3.2 Gen 2x2 connectors: 1
Number of RGB LED pin headers: 5
Number of CPU fan connectors: 2
BIOS
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package width: 270 mm
Package height: 68 mm
Package weight: 1.89 kg
Package depth: 268 mm
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
RAID support: Yes
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 6
RAID levels: 1, 10, 0
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port: Yes
DisplayPorts quantity: 1
Digital audio optical out: 1
Line-in: Yes
DisplayPort version: 1.4
Headphone outputs: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI version: 2.1
WiFi-AP antenna jack: 2
HDMI ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 2
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 25110
Battery
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Battery type: CR2032
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
Warranty: warranty 36 months
