Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
Features
Cooling type: Passive
Windows operating systems supported: Windows 11 x64, Windows 10 x64
PC health monitoring: Water cooling, Fan, Temperature, Voltage
Audio chip: Realtek ALC897
Motherboard form factor: ATX
Product colour: Black
Audio output channels: 7.1 channels
Power source type: ATX
Motherboard chipset: AMD B650
Motherboard chipset family: AMD
Memory
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Maximum internal memory per slot: 64 GB
ECC ?ompatibility: Non-ECC
Supported memory clock speed (max): 8000 MHz
Supported memory clock speeds: 5600, 7200, 7000, 6200, 6666, 7600 MHz, 7800, 6600, 5200, 4800, 6400, 8000, 6000, 4400, 6800
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 244 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Internal I/O
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
12V power connector: Yes
Front panel connector: Yes
Number of CPU fan connectors: 2
Thunderbolt headers: 1
USB 2.0 connectors: 2
Front panel audio connector: Yes
USB 3.2 Gen 2x2 connectors: 1
Number of RGB LED pin headers: 5
Serial port headers: 1
Number of EPS power connectors (8-pin): 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of water pump connectors: 2
ATX Power connector (24-pin): Yes
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging data
Package depth: 268 mm
Package height: 68 mm
Package width: 270 mm
Package weight: 1.9 kg
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
RAID levels: 10, 0, 1
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
Line-in: Yes
Headphone outputs: 1
HDMI version: 2.1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPort version: 1.4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
S/PDIF out port: Yes
USB 2.0 ports quantity: 4
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
2nd M.2 largest key size: 22110
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 5.0
Battery
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 1.66 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Warranty: warranty 36 months
