Περιγραφή
Processor
Compatible processor series: AMD Ryzen(TM) 5000 G-Series, AMD Ryzen(TM) 5000 Series, AMD Ryzen(TM) 4000 G-Series, AMD Ryzen(TM) 3000 Series
Processor manufacturer: AMD
Processor socket: Socket AM4
Graphics
Maximum resolution: 5120 x 2880 pixels
Graphics card family: AMD
High Dynamic Range (HDR) supported: Yes
HDCP: Yes
Features
Audio output channels: 7.1 channels
PC health monitoring: Temperature, Voltage, Water cooling, Fan
Motherboard form factor: Mini-ITX
Cooling type: Active
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Power source type: ATX
Motherboard chipset family: AMD
Motherboard chipset: AMD B550
Memory
Supported memory clock speeds: 2933, 3600, 3200 MHz, 4266, 4600, 2400, 3466, 2667, 3733, 4400, 3400, 3866, 4133, 4000, 4800, 2133, 5100 MHz, 5300, 5200
Number of memory slots: 2
Memory slots type: DIMM
Supported memory module capacities: 32GB
Supported memory types: DDR4 SO-DIMM
Maximum internal memory: 64 GB
Memory channels: Dual-channel
Unbuffered memory: Yes
Supported memory clock speed (max): 5300 MHz
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Network
Bluetooth: Yes
Bluetooth version: 5
Wi-Fi: Yes
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
Number of SATA connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
Audio connector: Yes
Power fan connector: Yes
TPM connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 2
CPU fan connector: Yes
USB 2.0 connectors: 1
12V power connector: Yes
Front panel audio connector: Yes
Number of M.2 (M) slots: 2
Number of LED strips supported: 2
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Storage controllers
RAID support: Yes
Supported storage drive types: SSD
Supported storage drive interfaces: M.2, PCI Express 3.0, PCI Express 4.0, SATA
RAID levels: 0, 10, 1
Rear panel I/O ports
HDMI ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Headphone outputs: 3
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Expansion slots
PCI Express x16 slots: 1
PCI Express x1 slots: 1
Warranty: warranty 36 months
