Περιγραφή
Design
Protection features: Water resistant
Mounting type: Ceiling
Product colour: Black
International Protection (IP) code: IP66
Power
Power consumption (max): 5 W
DC output voltage: 12
DC output current: 1 A
Power source type: DC, PoE
Security
Video motion detection: Yes
Active tampering alarm: Yes
Human and vehicle targets classification: Yes
Operational conditions
Storage temperature (T-T): -20 - 60 °C
Operating temperature (T-T): -20 - 40 °C
Operating relative humidity (H-H): 10 - 80%
Storage relative humidity (H-H): 0 - 90%
Weight & dimensions
Diameter: 11 cm
Weight: 380 g
Height: 100 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Performance
Wide Dynamic Range (WDR): Yes
Connectivity technology: Wired
Infrared (IR) cut-off filter: Yes
Day/night mode: Yes
Type: IP security camera
Placement supported: Indoor & outdoor
Audio
Audio formats supported: AAC, PCM
Built-in microphone: Yes
Storage
Card reader integrated: Yes
Maximum memory card size: 256 GB
Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Minimum illumination: 0 lx
Lens viewing angle, vertical: 53°
Lens viewing angle, diagonal: 108°
Lens viewing angle, horizontal: 94.5°
Image sensor
Sensor type: CMOS
Video
Total megapixels: 5 MP
Video compression formats: H.264+, H.264
Supported graphics resolutions: 1920 x 1080, 1280 x 720, 3072 x 1728
Maximum resolution: 3072 x 1728 pixels
Night vision
LED type: 4 IR LED
Night vision distance: 20 m
Night vision: Yes
Sustainability
Compliance certificates: Federal Communications Commission (FCC), UKCA, RoHS, CE
Warranty: Manufacturer warranty 24 months
