Περιγραφή
Technical details
Sustainability certificates: RoHS
Design
Mounting type: Wall
Weatherproof: Yes
Product colour: Black, White
International Protection (IP) code: IP66
Form factor: Dome
Power
DC output current: 1 A
DC output voltage: 12
Power source type: PoE
Power consumption (max): 5 W
Security
Video motion detection: Yes
Intelligent Video Surveillance (IVS) system features: Vehicle detection, Human detection
Alert notification type: E-mail
Built-in siren: Yes
Siren noise level: 100 dB
Operational conditions
Operating temperature (T-T): -20 - 50 °C
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 0 - 90%
Operating relative humidity (H-H): 10 - 80%
Weight & dimensions
Package type: Box
Weight: 380 g
Width: 110 mm
Height: 100 mm
Depth: 110 mm
Network
Streaming method: Multicast
Networking standards: IEEE 802.3af
Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Supported network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
System requirements
Mobile operating systems supported: iOS, Android
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Performance
Placement supported: Outdoor
Day/night mode: Yes
Virtual assistant: Amazon Alexa & Google Assistant
Colour temperature: 4500 K
Connectivity technology: Wired
Built-in light: Yes
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Packaging content
Cables included: LAN (RJ-45)
Number of cameras: 1
Manual: Yes
Screws included: Yes
Audio
Built-in speaker(s): Yes
Audio system: 2-way
Built-in microphone: Yes
Audio formats supported: PCM, AAC
Storage
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 256 GB
Card reader integrated: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Lens viewing angle, vertical: 43.6°
Lens viewing angle, horizontal: 78°
Lens viewing angle, diagonal: 94°
Image sensor
Number of sensors: 1
Sensor type: CMOS
Video
Video streaming: Yes
Image quality adjustment: Saturation, Contrast, Sharpness, Brightness
Supported graphics resolutions: 1920 x 1080 (HD 1080), 3072 x 1728, 1280 x 720 (HD 720)
Maximum resolution: 3072 x 1728 pixels
Supported video modes: 1080p, 720p
Video formats supported: H.264+, H.264
Frame rate: 25 fps
Total megapixels: 5 MP
Flip & mirror: Yes
Night vision
Night vision: Yes
LED type: IR
Number of illumination LEDs: 4
Night vision distance: 20 m
Lens system
Number of lenses: 1
Maximum aperture number: 2.1
Fixed focal length: 4 mm
Digital zoom: 6x
Zoom capability: Yes
Safety warning
Warnings: Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling., The product contains electronic components; do not dispose of with the normal household waste.
Warranty: warranty 24 months
