FLIR C3-X Thermal Imaging Camera Black 1800 Mah Vanadium Oxide Uncooled Focal Plane Arrays Built-In Display 128 x 96 Pixels Lcd 640 x 480 Pixels - (C3-X)
[Κωδικός : 949140]
*Το προϊόν δεν ειναι διαθέσιμο και δεν διατίθεται προς πώληση*
Περιγραφή
Technical details
Sustainability certificates: RoHS
Design
Housing material: Aluminium
Display resolution: 640 x 480 pixels
Built-in display: Yes
Display diagonal: 8.89 cm (3.5")
Display type: LCD
Operating temperature (T-T): -10 - 50 °C
International Protection (IP) code: IP54
Product colour: Black
Storage temperature (T-T): -40 - 70 °C
Package type: Box
Weight & dimensions
Height: 24 mm
Package width: 160 mm
Package weight: 517 g
Width: 138 mm
Weight: 190 g
Package depth: 117 mm
Depth: 84 mm
Package height: 94 mm
Performance
IFOV (spatial resolution): 7.9 mRad
Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range: -20 - 300 °C
Wi-Fi: Yes
Compatible memory cards: Not supported
Horizontal field of view: 53.6°
Sensor resolution (thermal module): 128 x 96 pixels
Thermal frame rate: 8.7 Hz
Standard palettes: Grayscale, High Contrast, Hot metal, Ironbow
GPS (satellite): No
Thermal sensitivity (NETD): 70 mK
Infrared spectral band: 8 - 14 μm
Packaging content
Manual: Yes
Wrist strap included: Yes
Batteries included: Yes
Cables included: USB Type-C
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
USB port: Yes
Battery
Battery capacity: 1800 mAh
Rechargeable battery: Yes
Input voltage: 3.7 V
Input current: 1 A
Battery life (max): 4 h
Battery technology: Lithium-Ion (Li-Ion)
Battery recharge time: 2 h
Lens system
Fixed focus: Yes
Warranty: warranty 24 months
Sustainability certificates: RoHS
Design
Housing material: Aluminium
Display resolution: 640 x 480 pixels
Built-in display: Yes
Display diagonal: 8.89 cm (3.5")
Display type: LCD
Operating temperature (T-T): -10 - 50 °C
International Protection (IP) code: IP54
Product colour: Black
Storage temperature (T-T): -40 - 70 °C
Package type: Box
Weight & dimensions
Height: 24 mm
Package width: 160 mm
Package weight: 517 g
Width: 138 mm
Weight: 190 g
Package depth: 117 mm
Depth: 84 mm
Package height: 94 mm
Performance
IFOV (spatial resolution): 7.9 mRad
Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays
Temperature measurement range: -20 - 300 °C
Wi-Fi: Yes
Compatible memory cards: Not supported
Horizontal field of view: 53.6°
Sensor resolution (thermal module): 128 x 96 pixels
Thermal frame rate: 8.7 Hz
Standard palettes: Grayscale, High Contrast, Hot metal, Ironbow
GPS (satellite): No
Thermal sensitivity (NETD): 70 mK
Infrared spectral band: 8 - 14 μm
Packaging content
Manual: Yes
Wrist strap included: Yes
Batteries included: Yes
Cables included: USB Type-C
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Ports & interfaces
USB port: Yes
Battery
Battery capacity: 1800 mAh
Rechargeable battery: Yes
Input voltage: 3.7 V
Input current: 1 A
Battery life (max): 4 h
Battery technology: Lithium-Ion (Li-Ion)
Battery recharge time: 2 h
Lens system
Fixed focus: Yes
Warranty: warranty 24 months
Χαρακτηριστικά
Μοντέλο
FLIR C3-X thermal imaging camera Black 1800 mAh Vanadium Oxide Uncooled Focal Plane Arrays Built-in display 128 x 96 pixels LCD 640 x 480 pixels - (C3-X)
Δείτε περισσότερα
Σύνολο: 1584.49€
