Περιγραφή
Design
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Fan location: Top
On/off switch: Yes
Number of fans: 1 fan(s)
Power
Max output current (+5Vsb): 2.5 A
Power Factor Correction (PFC) type: Active
Power protection features: OVP (overvoltage protection), SCP (short circuit protection), OPP (overload protection), SIP (surge and shock protection), UVP (undervoltage protection)
Total power: 550 W
AC input frequency: 50 - 60 Hz
Max output current (+3.3V): 18 A
Max output current (+5V): 18 A
Max output current (-12V): 0.3 A
Max output current (+12V): 41 A
Weight & dimensions
Height: 87 mm
Depth: 140 mm
Width: 150 mm
Performance
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS
Packaging data
DFU / User manual: Y
Ports & interfaces
Peripheral (Molex) power cable length: 410 mm, 555 mm
SATA power cable length: 410 mm, 555 mm, 700
PCI Express power connectors (6+2 pin): 1
Power connector length 16 PIN PCIe GEN5 : Not applicable
Peripheral (Molex) power connectors (4-pin): 2
EPS power connector (4+4 pin): Yes
Power connector 16 PIN PCIe GEN5: No
Number of SATA power connectors: 4
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 45 cm
PCI Express power cable length: 46 cm
Length of EPS power connectors (4+4 pin) : 70 cm
Length of PCI Express power cable (6-pin): 460 mm
PCI Express power connectors (6-pin) : 1
Warranty: Manufacturer warranty 36 months
