Eagle UPS BATTERY ES12-2.3 (12v 2.3ah)

TECHNICAL DATA

Nominal Voltage:12V
Capacity (25°C):
20HR(10.5V) - 2.3Ah
10HR(10.5V) - 2.1Ah
1HR (9.6V) - 1.5Ah

Dimensions:
Length 178±1mm / Width 35±1mm / Total Height: 67±1mm
Approx.Weight: 0.95kg ±3%

Terminal type: T1
Internal resistance (Fullycharged,25°C): Approx.60mΩ
Capacity affected by temperature: 40°C 102% / 25°C 100% / 0°C 85% (20HR) -15°C 65%

Self-discharge (25°C):
3 months: Remaining Capacity:91%
6 months: Remaining Capacity:82%
12 months: Remaining Capacity:65%

Nominal operating temperature: 25°C±3°C(77°F±5°F)

Operating temperature range:
Discharge: -15°C~50°C(5°F~122°F)
Charge: -10°C~50°C(14°F~122°F)
Storage -20°C~50°C(-4°F~122°F)

Float charging voltage (25°C): 13.60to13.80V
Temperature compensation: -18mV/°C
Cyclic charging voltage (25°C): 14.50to14.90V
Temperature compensation: -30mV/°C
Maximum charging current: 0.69A
Terminal material:  Copper
Maximum discharge current: 34.5A(5sec.)
Designed floating life (20°C): 10 years

Absorbent glass mat technology
Recognized by CE
ABS container
