Περιγραφή
Design
Plug and Play: Yes
Chipset: Realtek RTL8125B
LED indicators: Yes
Component for: Server/workstation
Internal: Yes
Product colour: Black
Operational conditions
Operating temperature (T-T): 5 - 50 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Height: 22 mm
Depth: 98 mm
Weight: 35.2 g
Width: 120 mm
Network
Maximum data transfer rate: 2500 Mbit/s
Ethernet LAN data rates: 100, 1000 Mbit/s, 10, 2500
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Wake-on-LAN ready: Yes
System requirements
Server operating systems supported: Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016
Linux operating systems supported: Yes
Windows operating systems supported: Windows 7, Windows 8, Windows 10
Packaging content
Mounting brackets included: Yes
Quick installation guide: Yes
Ports & interfaces
PCI version: 2.1
Host interface: PCI Express
PCI Card form factor: Full-height (low-profile)
Interface: Ethernet
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Logistics data
Harmonized System (HS) code: 85176990
Safety warning
Warnings: Avoid contact with liquids. If spilled, the product may be damaged., Please observe local regulations regarding the disposal of electronic waste., The product contains electronic components and should not be disposed of in the regular rubbish bin.
Warranty: warranty 24 months
