Περιγραφή
Design
On/off switch: Yes
Cooling type: Active
Fan diameter: 12 cm
Fan location: Top
Product colour: Black
Number of fans: 1 fan(s)
Power
Combined power (-12V): 3.6 W
Combined power (+5V): 110 W
Power protection features: Over power, Overheating, Surge protection, No load operation, Under voltage, Over current, Over voltage, Surge & inrush protection (SIP)
AC input voltage: 100 - 240 V
Power Good signal delay range: 100 - 150 ms
Combined power (+3.3V): 110 W
Max output current (+12V): 62.5 A
Combined power (+12V): 750 W
Max output current (+3.3V): 20 A
Max output current (+5Vsb): 3 A
Efficiency: 80%
AC input frequency: 50/60 Hz
Max output current (+5V): 20 A
Total power: 750 W
Hold time: 16 ms
Power Factor Correction (PFC) type: Active
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
Mean time between failures (MTBF): 100000 h
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Packaging data
Package type: Box
Certificates
Compliance certificates: RoHS, WEEE
Ports & interfaces
Motherboard power connector: 24-pin ATX
Motherboard power cable length: 54 cm
Cabling type: Non-Modular
Warranty: warranty 24 months
