Περιγραφή
Design
Fan diameter: 12 cm
On/off switch: Yes
Fan location: Front
Product colour: Black
Number of fans: 1 fan(s)
Cooling type: Active
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Combined power (+3.3V): 100 W
Power Good signal delay range: 100 - 150 ms
Combined power (+5V): 100 W
Combined power (+12V): 648 W
Power protection features: Under voltage, No load operation, Surge & inrush protection (SIP), Over power, Overheating, Surge protection, Short circuit, Over voltage
Power Factor Correction (PFC) type: Active
Hold time: 16 ms
Efficiency: 90%
Total power: 650 W
Combined power (+5Vsb): 15 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 140 mm
Performance
ATX version: 3.1
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging data
Package type: Box
Packaging content
Cables included: AC
Cable tie(s) included: Yes
Ports & interfaces
Number of SATA power connectors: 6
CPU power cable length: 70 cm
Peripheral (Molex) power connectors (4-pin): 2
ATX power connector (20+4 pin): Yes
PCI Express power connectors (6+2 pin): 3
Cabling type: Non-Modular
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (16-pin): 1
CPU power connector (4+4 pin): 2
Safety warning
Warnings: Avoid contact of the product with water or other liquids., Do not open the case - risk of electric shock., The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
Warranty: warranty 24 months
