Περιγραφή
Design
Fan diameter: 12 cm
Cooling type: Active
Number of fans: 1 fan(s)
Fan location: Top
Product colour: Black
On/off switch: Yes
Power
Power protection features: No load operation, Under voltage, Over current, Overheating, Surge protection, Over voltage, Surge & inrush protection (SIP), Over power
Combined power (+3.3V): 120 W
Total power: 1000 W
AC input voltage: 100 - 240 V
Efficiency: 90%
AC input frequency: 50/60 Hz
Combined power (-12V): 3.6 W
Max output current (+12V): 83.3 A
Max output current (+5V): 22 A
Combined power (+12V): 999.6 W
Combined power (+5V): 120 W
Hold time: 16 ms
Power Factor Correction (PFC) type: Active
Max output current (+3.3V): 22 A
Power Good signal delay range: 100 - 150 ms
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 85 mm
Width: 150 mm
Depth: 150 mm
Performance
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Bearing technology: FDB
ATX version: 3.1
Packaging data
Package type: Box
Certificates
Compliance certificates: RoHS, WEEE
Ports & interfaces
Cabling type: Modular
Motherboard power connector: 24-pin ATX
Motherboard power cable length: 54 cm
Warranty: Gwarancja 144 miesiace
