Περιγραφή
Technical details
Sustainability certificates: ErP, Triman
Sustainability compliance: Yes
Design
Product colour: Black
Fan location: Top
Cooling type: Active
Fan diameter: 12 cm
On/off switch: Yes
Number of fans: 1 fan(s)
Power
Max output current (+5Vsb): 3 A
AC input frequency: 50/60 Hz
Max output current (+3.3V): 20 A
Power protection features: Under voltage, Over current, Over power, Surge & inrush protection (SIP), Over voltage, No load operation, Overheating, Surge protection
Hold time: 16 ms
AC input voltage: 100 - 240 V
Input current: 9 - 4.5 A
Max output current (+5V): 20 A
Total power: 800 W
Max output current (+12V): 54 A
Max output current (-12V): 0.3 A
Power Good signal delay range: 100 - 150 ms
Combined power (-12V): 3.6 W
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Combined power (+12V): 648 W
Efficiency: 85%
Power Factor Correction (PFC) type: Active
Combined power (+5Vsb): 15 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
Purpose: PC
ATX version: 3.0
Power supply unit (PSU) form factor: ATX
Bearing technology: HYB
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Packaging data
Package type: Box
Certificates
Compliance certificates: RoHS, WEEE
Ports & interfaces
SATA power cable length: 650, 550, 450 mm
PCI Express power connectors (16-pin): 1
Peripheral (Molex) power connectors (4-pin): 2
Number of SATA power connectors: 6
Motherboard power cable length: 55 cm
CPU power connector (4+4 pin): Yes
Cabling type: Non-Modular
PCI Express power connectors (6+2 pin): 3
ATX power connector (20+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
Warranty: warranty 24 months
