Technical details
Sustainability certificates: ErP, Triman
Sustainability compliance: Yes
Compliance certificates: RoHS, WEEE
Design
Cooling type: Active
Product colour: White
Fan diameter: 12 cm
On/off switch: Yes
Fan location: Top
Number of fans: 1 fan(s)
Power
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Input current: 10 - 5 A
Efficiency: 85%
Combined power (+3.3V): 100 W
Total power: 750 W
Power protection features: Overheating, Surge protection, Surge & inrush protection (SIP), Under voltage, Over current, No load operation, Over power, Over voltage
Max output current (+12V): 62.5 A
Combined power (+5V): 100 W
Power Factor Correction (PFC) type: Active
Combined power (-12V): 3.6 W
Hold time: 16 ms
Max output current (+5V): 20 A
Power Good signal delay range: 100 - 150 ms
Combined power (+12V): 750 W
Combined power (+5Vsb): 15 W
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 20 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 86 mm
Width: 150 mm
Depth: 140 mm
Performance
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: HYB
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Packaging data
Package type: Box
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 3
Cabling type: Non-Modular
ATX power connector (20+4 pin): Yes
Number of SATA power connectors: 7
PCI Express power connectors (16-pin): 1
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Warranty: warranty 24 months
