Περιγραφή
Design
Mounting type: Wall
Form factor: Bullet
International Protection (IP) code: IP67
Product colour: White
Housing material: Metal
Power
Power consumption (Power over Ethernet (PoE)): 4.4 W
DC output voltage: 12
Power consumption (max): 3.8 W
Power consumption (typical): 1.6 W
Power source type: DC, PoE
Security
Video motion detection: Yes
Mirror: Yes
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Depth: 166.2 mm
Width: 70 mm
Height: 70 mm
Weight: 480 g
Network
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Bluetooth: No
System requirements
Mobile operating systems supported: iOS, Android
Performance
Day/night mode: Yes
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Packaging data
Package weight: 590 g
Packaging content
Number of cameras: 1
Audio
Signal-to-Noise Ratio (SNR): 56 dB
Voice codecs: PCM, G.711a, G.726, G.711Mu
Built-in microphone: Yes
Storage
ROM capacity: 128 MB
Maximum memory card size: 256 GB
Built-in HDD: No
Internal memory: 128 MB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Camera
White balance: Auto, Outdoor, Manual, Street lamp, Custom modes, Natural
Lens viewing angle, vertical: 56°
Camera pan control: Yes
Lens viewing angle, horizontal: 107°
Angle of rotation: 360°
Camera tilt control: Yes
Lens viewing angle, diagonal: 127°
Camera shutter type: Electronic
Camera shutter speed: 1/3 - 1/100000 s
Pan range: 0 - 360°
Tilt angle range: 0 - 90°
Image sensor
Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
Number of sensors: 1
Sensor type: CMOS
Progressive scan: Yes
Video
Gain control type: Auto/Manual
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video compression formats: H.265, H.264H, H.264B, H.264, M-JPEG
Privacy masking: Yes
Total megapixels: 2 MP
Video streaming: Yes
Region of Interest (ROI) encoding: Yes
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Supported graphics resolutions: 1280 x 720 (HD 720), 352 x 288, 640 x 480 (VGA), 1920 x 1080 (HD 1080), 352 x 240, 704 x 480, 704 x 576, 1280 x 960
Back Light Compensation (BLC): Yes
Maximum resolution: 1920 x 1080 pixels
Highlight Compensation (HLC): Yes
Night vision
Number of illumination LEDs: 2
Night vision: Yes
Night vision distance: 30 m
LED type: IR
Lens system
Identify distance: 4.4 m
Closest focusing distance: 0.7 m
Observe distance: 17.5 m
Recognize distance: 8.8 m
Fixed focal length: 2.8 mm
Detect distance: 43.9 m
Minimum aperture number: 1.6
Warranty: warranty 36 months
