Περιγραφή
Design
International Protection (IP) code: IP67
Housing material: Metal
Product colour: White
Mounting type: Ceiling/wall
Power
Power source type: PoE
Security
Intelligent Video Surveillance (IVS) system features: Human detection, Intrusion, Vehilce detection
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -30 - 60 °C
Management features
Web browser: Yes
Management software: SmartPSS Lite; DSS; DMSS
Weight & dimensions
Length: 238.5 mm
Height: 90.7 mm
Width: 90.7 mm
Weight: 760 g
Network
Cabling technology: 10/100Base-T
Quality of Service (QoS) support: Yes
Streaming method: Multicast
Number of users: 20 user(s)
System requirements
Mobile operating systems supported: iOS, Android
Performance
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Packaging content
Number of cameras: 1
Storage
ROM capacity: 128 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
White balance: Lamp, Regional custom, Natural, Manual, Outdoor, Auto
Pan range: 0 - 360°
Tilt angle range: 0 - 90°
Image sensor
Progressive scan: Yes
Sensor type: CMOS
Number of sensors: 1
Video
Supported graphics resolutions: 3840 x 2160, 1920 x 1080, 1280 x 720, 2880 x 1620, 640 x 480 (VGA), 3072 x 2048, 3072 x 1728, 1280 x 960
Maximum resolution: 3840 x 2160 pixels
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Video compression formats: H.265, H.264H, H.264B, H.264, M-JPEG
Total megapixels: 8 MP
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes
Flip & mirror: Yes
3D NR (Noise Reduction): Yes
Privacy masking: Yes
Gain control type: Auto/Manual
Lens system
Maximum aperture number: 1.5
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Warranty: warranty 36 months
