Περιγραφή
Design
Mounting type: Ceiling/Wall/Pole
Form factor: Bullet
International Protection (IP) code: IP67
Product colour: White
Housing material: Metal
Power
Power consumption (Power over Ethernet (PoE)): 3.2 W
Power consumption (max): 6.1 W
Power source type: DC, PoE
Power consumption (typical): 2.3 W
Max power consumption (Power over Ethernet (PoE)) : 7,4 W
Security
Mirror: Yes
Video motion detection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Operating temperature (T-T): -40 - 60 °C
Management features
Management software: Smart PSS Lite; DSS; DMSS
Weight & dimensions
Width: 80.2 mm
Depth: 197.9 mm
Weight: 570 g
Height: 76.2 mm
Network
Number of users: 20 user(s)
Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration
Networking standards: IEEE 802.3af
System requirements
Mobile operating systems supported: Android, iOS
Performance
Day/night mode: Yes
Placement supported: Indoor & outdoor
Wide Dynamic Range (WDR): Yes
Type: IP security camera
Connectivity technology: Wired
Built-in light: Yes
Packaging content
Number of cameras: 1
Audio
Voice codecs: G.711Mu, PCM, G.711a, G.726
Storage
RAM capacity: 256 MB
ROM capacity: 128 MB
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Pan range: 0 - 360°
Camera shutter type: Electronic
Camera shutter speed: 1/3 - 1/100000 s
Tilt angle range: 0 - 90°
Angle of rotation: 360°
White balance: Manual, Auto, Custom modes, Street lamp, Outdoor, Natural
Number of Privacy masking areas: 4
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Video
Video compression formats: H.264, H.265, MJPEG, H.264B, H.264H
Noise reduction technology: 3D noise reduction
Frame rate: 30 fps
Total megapixels: 8 MP
Region of Interest (ROI) encoding: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Maximum resolution: 3840 x 2160 pixels
Bit rate: H.264: 32 kbps-8192 kbps; H.265: 12 kbps-8192 kbps
Supported graphics resolutions: 704 x 480, 2688 x 1520, 1920 x 1080, 3072 x 2048, 352 x 288, 1280 x 720, 2880 x 1620, 3840 x 2160, 640 x 480, 2048 x 1536, 352 x 240, 2304 x 1296, 704 x 576, 1280 x 960, 3072 x 1728
Highlight Compensation (HLC): Yes
Night vision
Night vision: Yes
Night vision distance: 50 m
Number of illumination LEDs: 4
Lens system
Number of lenses: 3
Warranty: Manufacturer warranty 24 months
