Περιγραφή
Design
Mounting type: Ceiling
Form factor: Dome
International Protection (IP) code: IP67
Housing material: Metal, Plastic
Product colour: White
Power
Power consumption (typical): 2.2 W
Power consumption (max): 7.1 W
Power source type: DC
DC output voltage: 12
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -40 - 60 °C
Management features
Dedicated application: DMSS (Android, iOS)
Weight & dimensions
Diameter: 109,9 mm
Weight: 353 g
Height: 102.2 mm
Network
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Wi-Fi: Yes
System requirements
Mobile operating systems supported: Android, iOS
Performance
Connectivity technology: Wired
Light alarm: Yes
Type: IP security camera
Audible alarm: Yes
Placement supported: External / Internal
Human detection: Yes
Packaging content
Number of cameras: 1
Audio
Built-in loudspeaker: Yes
Audio formats supported: PCM, G.711a, G.711Mu, G.726
Built-in microphone: Yes
Storage
Maximum memory card size: 256 GB
Compatible memory cards: MicroSD (TransFlash)
Camera
Lens viewing angle, horizontal: 78°
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 - 1/100000 s
Lens viewing angle, vertical: 41°
Viewing angle, horizontal (2.8mm lens): 98°
Viewing angle, diagonal: 94°
Viewing angle, vertical (2.8mm lens): 55°
Viewing angle, diagonal (2.8mm lens): 115°
Image sensor
Optical sensor size: 25.4 / 3 mm (1 / 3")
Sensor type: CMOS
Video
Video compression formats: H.265+, H.264H, H.264, H.264B, H.265
Bit rate: H.264: 32 - 4096Kbps; H.265: 12 - 4096Kbps
Supported graphics resolutions: 2304 x 1296, 1280 x 960, 1920 x 1080, 1280 x 720, 2560 x 1440, 640 x 480
Maximum resolution: 2560 x 1440 pixels
Total megapixels: 4 MP
Region of Interest (ROI) encoding: Yes
Frame rate: 30 fps
Video streaming: Yes
Night vision
LED type: IR / White light LED
Number of illumination LEDs: 2
Night vision: Yes
Night vision distance: 30 m
Lens system
Maximum aperture number: 1.6
Focal length range: 2.8 - 3.6 mm
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage.
Warranty: Manufacturer warranty 36 months
