Περιγραφή
Design
Mounting type: Wall/ceiling
Product colour: White
International Protection (IP) code: IP67
Housing material: Metal, Plastic
Form factor: Tube/dome
Power
Power consumption (max): 4.5 W
Power consumption (Power over Ethernet (PoE)): 3.5 W
Power consumption (typical): 2.5 W
Power source type: DC, PoE
DC output voltage: 12
Operational conditions
Storage temperature (T-T): -40 - 55 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -40 - 55 °C
Management features
Dedicated application: DMSS (Android, iOS)
Web-based management: Yes
Web browser: Yes
Weight & dimensions
Weight: 350 g
Height: 85.6 mm
Product diameter: 94 mm
Network
Networking standards: IEEE 802.3af
Bluetooth: No
4G LTE: No
Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
Wi-Fi: No
System requirements
Mobile operating systems supported: Android, iOS
Performance
Signal-to-Noise Ratio (SNR): 56 dB
Placement supported: Outdoor
Connectivity technology: Wired
Type: IP security camera
Packaging content
Number of cameras: 1
Audio
Audio codecs: PCM, G.711a G.711Mu, G.726
Built-in microphone: Yes
Two-way talk: N
Built-in loudspeaker: No
Storage
ROM capacity: 128 MB
RAM capacity: 256 MB
Camera
Vertical rotation angle: 0 - 78°
Adjustment shutter speed: Auto/Manual
Camera shutter speed: 1/3 - 1/100000 s
Minimum illumination: 0.008 lx
Lens viewing angle, vertical: 58°
Motion detection : Yes
Lens viewing angle, horizontal: 110°
Viewing angle, diagonal: 132°
Horizontal rotation angle: 0 - 360°
People detection : Yes
Image sensor
Sensor type: HD CMOS
Progressive scan: Yes
Number of sensors: 1
Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video
Frame rate: 20 / 25 / 30 fps
Maximum resolution: 3840 x 2160 pixels
Video compression formats: H.265, H.264, H.264B, H.264+, H.264H, H.265+, M-JPEG
Total megapixels: 8 MP
Video streaming: Yes
Night vision
Number of illumination LEDs: 1 / 1
LED type: IR / White light LED
Night vision: Yes
Night vision distance: 30 m
Lens system
Focal length range: 2.8 mm
Lens type: Fixed focal length lens
Maximum aperture number: 1.6
Number of lenses: 1
Closest focusing distance: 1.5 m
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Warranty: Manufacturer warranty 36 months
