Camera
Image Sensor
1/3.2" CMOS
Max. Resolution
2304 (H) x 1296 (V)
Electronic Shutter Speed
Auto/Manual 1/3 s-1/100,000 s
Illumination Distance
Up to 10 m (32.81 ft) (IR)
Illuminator On/Off Control
Auto
Illuminator Number
1 (IR LED)
Angle Adjustment
Pan: 0° to 355°;
Tilt: -5° to 80°
Lens
Max. Aperture
F2.0
Field of View
2.8mm H: 81°; V: 44°; D: 95°
3.6mm H: 69°; V: 36°; D: 81°
Intelligence
Human Detection
Yes
Video
Video Compression
H.265
Video Frame Rate
Main stream: 2304 x 1296@15 fps
sub stream: 640 x 360@15 fps
Resolution
3M (2304 x 1296); HD (640 x 360)
Video Bit Rate
H.265: 80 kbps-4096 kbps
Day/Night
Auto(ICR)/Color/B/W
WDR ,DWDR
Motion Detection
Image Rotation
0°/180°
Audio
Built-in MIC
Yes, built-in Mic
Built-in Speaker
Yes, built-in speaker
Audio Compression
G.711a
Network
Wi-Fi
IEEE 802.11b/g/n/ax 2.412-2.472 GHz,2.4G
Storage
Micro SD card (up to 256 GB)
Management Software
DMSS
Mobile Client
iOS;Android
Power
Power Supply
5 VDC
Power Consumption
Basic: 1.9 W;
Max.: 4.5 W (live + IR + PT rotation)
Environment
Operating Temperature
-10 °C to +45 °C (+14 °F to +113 °F)
Operating Humidity
<=95% (RH), non-condensing
Structure
Casing Material
Plastic
Product Dimensions Π90.9mm x Υ120.8 mm
Net Weight 370 g
