Περιγραφή
Performance
Layer
Layer 2
Switching Capacity
32 Gbps
Packet Forwarding Rate
23.808 Mpps
Packet Buffer Memory
4.1 Mb
MAC Table Size
8K
Hardware Feature
Standard Power Supply
Yes
PoE
Yes
Ethernet Port
16
Ethernet Port Rate
1 Gbps
Number of Bussiness Card Slots
Port 1-16:16 x RJ-45 10/100/1000Mbps(PoE)
Power Supply
100V AC -240V AC
Operating Temperature
-10°C to +55°C (14°F to +131°F)
Operating Humidity
10%-90%
Storage Humidity
5%-95%
Power Consumption
Idling: 18W
Full load: 190W
PoE
PoE Standard
IEEE802.3af, IEEE802.3at, Hi-PoE
PoE Budget
Port 1-port 2 <= 60W, port 3-port 16 <= 30W, total <= 190W
PoE Pin Assignment
PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
General
ESD
Air discharge: 8kV
Contact discharge: 6kV
Thunderproof
Common mode: 4kV
Differential mode: 2kV
Product Dimensions
285 mm x 104.6 mm x 28 mm (11.22" x 4.12" x 1.10")
Packaging Dimensions
455 mm x 270 mm x 92 mm (17.91" x 10.63" x 3.62")
Κατασκευαστής : Dahua
Ports 100/1000 fixed : 16
Part Number : DH-SG1016P
Μεικτό βάρος : 1,15 kg
Καθαρό βάρος : 0,95 kg
EAN Number : 6923172571847
Εγγύηση : 3 έτη
