Hardware
Data Transmission Port
Port 1-8: 8 x RJ-45 10/100 Mbps (PoE)
Port 9: 1 x RJ-45 10/100/1000 Mbps (uplink)
Port 10: 1 x SFP 1000 Mbps (uplink)
Power Supply
48 V - 57 V DC
Operaing Temperature
-30 °C to +65 °C (-22 °F to +149 °F)
Operating Humidity
5% - 95% (RH)
Power Consumption
Idling: 3 W
Full load: 96 W
Performance
Capacity
7.6 Gbps
Packet Forwarding Rate
4.17 Mbps
Packet Buffer Memory
1 Mbit
MAC Table Size
8K
Communication Standard
IEEE802.3/IEEE802.3u/IEEE802.3X/IEEE 802.3ab/IEEE 802.3z
PoE
PoE Standard
IEEE802.3af/ IEEE802.3at/ Hi-PoE/ IEEE802.3bt
PoE Power
Port 1-2 <= 90 W, Port 3-8 <= 30W, total<= 96 W
Power Consumption Management
Yes
PoE Pin Assignment
1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
Long Distance PoE
250 m long distance PoE transmission
General
Lightning Protection
Air discharge: 8 kV
Contact discharge: 6 kV
ESD Protection
Common mode: 4kV
Differential mode: 2kV
Net Weight
0.54 kg
Gross Weight
1.35 kg
Product Dimensions
150 mm x 100 mm x 42 mm (5.91" x 3.94" x 1.65")
Κατασκευαστής : Dahua
Rackable : Οχι
Manageable : Οχι
Τύπος : Switch
Part Number : 1.0.01.20.10608
Μεικτό βάρος : 1,35 kg
Καθαρό βάρος : 0,57 kg
EAN Number : 6923172503862
Εγγύηση : 3 έτη
