Chieftec Core Power Supply Unit 700 W 24-Pin Atx PS/2 Black - (BBS-700S)

Design
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Number of fans: 1 fan(s)

Power
AC input frequency: 47 - 63 Hz
AC input voltage: 100 - 240 V
Max output current (+5V): 22 A
Combined power (+5Vsb): 12.5 W
Input current: 10 A
Power Factor Correction (PFC) type: Active
Power protection features: Short circuit, Over voltage, Overload
Max output current (+12V1): 58 A
Total power: 700 W
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 2.5 A
Max output current (+3.3V): 22 A
Combined power (-12V): 3.6 W

Weight & dimensions
Width: 140 mm
Depth: 150 mm
Height: 86 mm
Weight: 1.72 kg

Performance
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: PS/2

Packaging data
Package weight: 2.13 kg

Ports & interfaces
Floppy drive power connector: 1
Floppy disk drive connector: Yes
Motherboard power connector: 24-pin ATX
CPU power cable length: 65 cm
PCI Express power connectors (6+2 pin): 4
Cabling type: Non-Modular
Number of SATA power connectors: 6
CPU power connector (4+4 pin): Yes
SATA power cable length: 150, 500 mm
PCI Express power cable length: 50 cm
Peripheral (Molex) power cable length: 150, 500 mm
Peripheral (Molex) power connectors (4-pin): 3

Logistics data
Harmonized System (HS) code: 84733020


Warranty: warranty 24 months
