Biostar Μητρική 4x DDR4 AM4 USB 3.2 HDMI ATX Ver. 5.0 - (B550GTA)

BIOSTAR Μητρική B550GTA, 4x DDR4, AM4, USB 3.2, HDMI, ATX, Ver. 5.0
-Supports AMD 3rd Gen Ryzen (Matisse/ Renoir) processors
-AMD B550 single chip architecture
-Supports 4-DIMM DDR4-4933+(OC)/4800(OC)/4600(OC)/4400(OC)/4000(OC)/3800(OC)/3600(OC)/3200(OC)/2933/2667/2400/2133/1866 up to 128GB maximum capacity
-Supports USB 3.2 Gen2
-Supports PCIe M.2 4.0 (64Gb/s)
-Supports HDMI 4K resolution
-Supports Realtek 2.5GbE LAN
Τεχνικά Χαρακτηριστικά
Chipset: AMD B550
CPU support: Socket AM4 support AMD 3rd Gen AMD Ryzen(TM) (Matisse / Renoir) processors, Support for future AMD Ryzen processors with BIOS update
Memory: 4x DDR4 DIMM, Max. Supports up to 128 GB Memory
Integrated video: By CPU model, Supports DX12, HDCP
Storage: 6x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10, 2x M.2 (M Key) Socket: (Supports M.2 Type 2242/ 2260/ 2280 SSD module, Supports PCIe 4.0 x 4 (64Gb/s)/ 3.0 x 4 (32Gb/s) - NVMe/ AHCI SSD, Supports SATA III (6.0Gb/s) SSD)
LAN: RTL8125, 10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability, Supports Realtek 2.5GbE LAN
Audio codec: ALC1150, 7.1 Channels, High Definition Audio, Hi-Fi(Front)
USB: 1x USB 3.2 (Gen2) Type-C port (1 on rear I/O), 1x USB 3.2 (Gen2) Type-A port (1 on rear I/O), 6x USB 3.2 (Gen1) port (4 on rear I/Os and 2 via internal headers), 6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion slot: 1x PCI Slot, 1 x PCIe 4.0/ 3.0 x16 Slot (PEX16_1), 1x PCIe 3.0 x 16 Slot (PEX16_SB_1): Supports x 4 lanes, 3x PCIe 3.0 x 1 Slot
Dimension: ATX Form Factor Dimension: 30.5cm x 24.4cm ( W x L )
OS support: Supports Windows 10(64bit)
Rear I/O:
1x PS/2 Keyboard / Mouse
1x DVI-D Port
1x DP Port
1x HDMI Port
1x LAN port
1x USB 3.2 (Gen2) Type-C Port
1x USB 3.2 (Gen2) Type-A Port
4x USB 3.2 (Gen1) Port
2x USB 2.0 Port
3x Audio Jack
Internal I/O:
6x SATA III (6.0Gb/s) Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x CPU water cooling connector (OPT_FAN1)
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x S/PDIF out Connector
1x COM Port Header
2x LED Header (5V)
1x LED Header (12V)





Κωδικός είδους:B550GTA

Κατασκευαστής:BIOSTAR

Εγγύηση:24 μήνες

Διαστάσεις Συσκευασίας:34 x 7.5 x 28.5 cm

Βάρος Συσκευασίας:1.578 Kg

Τύπος συσκευασίας:Retail
