Technical details
Sustainability certificates: ENERGY STAR, ErP
Design
On/off switch: Yes
Fan speed: 0 - 2100 RPM
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Power
Combined power (-12V): 3.6 W
Power factor: 0.98
Max output current (+5V): 20 A
Power protection features: Surge & inrush, Under voltage, Over current, Over power, Short circuit, Over voltage, Overheating
Max output current (+3.3V): 20 A
Max output current (+5Vsb): 3 A
Max output current (+12V1): 54.17 A
Combined power (+3.3V): 120 W
Combined power (+5V): 120 W
Combined power (+12V): 650 W
Efficiency: 89.7%
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Total power: 650 W
Hold time: 17.04 ms
AC input frequency: 50 Hz
Input current: 4 A
AC input voltage: 200 - 240 V
Number of +12V rail(s): 1
Weight & dimensions
Height: 140 mm
Width: 150 mm
Depth: 86 mm
Weight: 1.97 kg
Performance
Purpose: PC
EPS version: 2.92
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: Rifle
Noise level: 30.9 dB
Packaging data
Package width: 195 mm
Package depth: 268 mm
Package height: 97 mm
Package weight: 2.4 kg
Package type: Box
Certificates
Waste Electrical and Electronic Equipment (WEEE) compliance: Yes
Compliance certificates: CB, WEEE, TUV mark, RoHS, CE, UKCA
Ports & interfaces
CPU P4 connector (4-pin): 1
PCI Express power connectors (6+2 pin): 2
Number of SATA power connectors: 5
Cabling type: Non-Modular
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4-pin): 1
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (12-pin): 1
Other features
Cable ties included: Yes
Screws included: Yes
Logistics data
Shipping (inner) case length: 55.6 cm
Shipping (inner) case height: 21.8 cm
Shipping (inner) case gross weight: 15.2 kg
Shipping (inner) case width: 31.1 cm
Products per shipping (inner) case: 6 pc(s)
Warranty: warranty 60 months
