Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Processor manufacturer: AMD
Graphics
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Product colour: White
Motherboard form factor: ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11
Memory
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 8000 MHz
ECC ?ompatibility: ECC & Non-ECC
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Bluetooth: Yes
Wake-on-LAN ready: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.4
Internal I/O
S/PDIF out connector: Yes
Number of CPU fan connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
Number of water pump connectors: 1
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
Number of RGB LED pin headers: 3
USB 2.0 connectors: 2
Number of EPS power connectors (8-pin): 2
Chassis intrusion connector: Yes
USB 3.2 Gen 2x2 connectors: 1
Number of COM connectors: 1
12V power connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Packaging content
Screws included: Yes
Cables included: SATA
Antenna included: Yes
Storage controllers
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 10, 0, 1, 5
Number of storage drives supported: 7
Rear panel I/O ports
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-A, USB Type-C
USB4 Gen 3x2 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Headphone outputs: 3
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Microphone in: Yes
WiFi-AP antenna jack: 2
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 2
Warranty: warranty 36 months
