Περιγραφή
Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
Features
Motherboard form factor: ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11
Audio output channels: 7.1 channels
Product colour: Multicolour
Motherboard chipset: AMD X870
Memory
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 4
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 8000 MHz
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Bluetooth version: 5.4
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
Internal I/O
12V power connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Number of COM connectors: 1
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 4
Chassis intrusion connector: Yes
USB 2.0 connectors: 2
S/PDIF out connector: Yes
Number of CPU fan connectors: 1
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Antenna included: Yes
Storage controllers
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 5, 0, 10
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB4 Gen 3x2 ports quantity: 2
WiFi-AP antenna jack: 2
Microphone in: Yes
USB 2.0 ports quantity: 4
Line-in: Yes
USB connector type: USB Type-C, USB Type-A
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 1
Warranty: warranty 36 months
