Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11, Windows 10 x64
Audio output channels: 7.1 channels
Motherboard chipset: AMD B650
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Memory
Supported memory clock speeds: 4800, 6000, 5200, 6400, 5800, 5400, 6200, 5600, 5000
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Memory slots type: DIMM
Number of memory slots: 4
ECC ?ompatibility: ECC & Non-ECC
Memory channels: Dual-channel
Supported memory clock speed (max): 6400 MHz
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Front panel audio connector: Yes
Number of SATA III connectors: 8
Number of chassis fan connectors: 2
12V power connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of COM connectors: 1
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
CPU fan connector: Yes
Peripheral (Molex) power connectors (4-pin): 1
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging data
Package weight: 1.61 kg
Package width: 275 mm
Package height: 67.4 mm
Package depth: 275 mm
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 0, 10
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Number of storage drives supported: 6
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 1
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
Microphone in: Yes
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
HDMI ports quantity: 1
DisplayPorts quantity: 2
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 4.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Warranty: warranty 36 months
