Processor
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Parallel processing technology support: Not supported
Features
Motherboard chipset: AMD B650
Product colour: Black
Audio chip: Realtek ALC1220P
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11, Windows 10 x64
Audio output channels: 7.1 channels
Cooling type: Passive
Motherboard form factor: ATX
Memory
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Bluetooth: Yes
Bluetooth version: 5.3
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
Thunderbolt headers: 1
Chassis intrusion connector: Yes
Number of chassis fan connectors: 4
CPU fan connector: Yes
Front panel connector: Yes
Number of COM connectors: 1
USB 2.0 connectors: 2
12V power connector: Yes
Number of CPU fan connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging data
Package weight: 1.39 kg
Package width: 353 mm
Package height: 68 mm
Package depth: 273 mm
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
RAID levels: 10, 5, 1, 0
Number of storage drives supported: 7
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 6
Line-in: Yes
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Microphone in: Yes
WiFi-AP antenna jack: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
2nd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 2
1st M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
Warranty: warranty 36 months
