Περιγραφή
Design
Fan location: Top
Product colour: Black
Number of fans: 1 fan(s)
On/off switch: Yes
Cooling type: Active
Power
Max output current (+5Vsb): 3 A
Power protection features: Over power, Under voltage, Over current, Short circuit, Over voltage, Overheating
Max output current (+12V): 54.16 A
Power Factor Correction (PFC) type: Active
Max output current (+3.3V): 12 A
Combined power (+5V): 80 W
Combined power (+3.3V): 80 W
Total power: 650 W
Combined power (-12V): 3.6 W
Combined power (+12V): 650 W
Max output current (+5V): 12 A
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Weight & dimensions
Weight: 1.25 kg
Depth: 150 mm
Width: 140 mm
Height: 86 mm
Performance
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 120000 h
Bearing technology: DBB
ATX version: 3.1
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
Packaging data
Package type: Box
Package height: 127 mm
Package depth: 182 mm
Package weight: 2.07 kg
Package width: 282 mm
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
PCI Express power connectors (6+2 pin): 2
Number of SATA power connectors: 4
Cabling type: Fully-Modular
Peripheral (Molex) power connectors (4-pin): 2
CPU power connector (4+4 pin): Yes
CPU power cable length: 65 cm
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 400 mm, 120
Motherboard power cable length: 50 cm
Peripheral (Molex) power cable length: 400 mm, 120 mm
Warranty: warranty 84 months
