Περιγραφή
Processor
Processor socket: Socket AM4
Compatible processor series: AMD Athlon, AMD Ryzen 3000 Series
Processor manufacturer: AMD
Maximum number of SMP processors: 1
Graphics
Parallel processing technology support: Not supported
Features
Motherboard chipset family: AMD
Motherboard form factor: micro ATX
Audio chip: Realtek ALC887 / Realtek ALC897
Motherboard chipset: AMD B550
Component for: PC
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64
Memory
Unbuffered memory: Yes
Supported memory clock speeds: 3200 MHz, 2666, 4266, 2133, 3866, 3466, 3000, 2400, 2800, 4133, 4000, 4800 MHz, 3600, 3333, 4466, 4600, 3733, 4400
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR4-SDRAM
Memory slots type: DIMM
ECC ?ompatibility: ECC
Weight & dimensions
Height: 51 mm
Width: 244 mm
Depth: 244 mm
Network
Wake-on-LAN ready: Yes
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
LAN controller: Realtek RTL8111H
Internal I/O
Number of chassis fan connectors: 2
Front panel audio connector: Yes
CPU fan connector: Yes
Number of COM connectors: 1
Number of SATA III connectors: 4
Chassis intrusion connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
Number of EATX power connectors: 1
ATX Power connector (24-pin): Yes
Thunderbolt headers: 1
12V power connector: Yes
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
Packaging content
Cables included: SATA
Drivers included: Yes
Storage controllers
RAID levels: 1, 0, 10
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DisplayPorts quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
PS/2 ports quantity: 2
USB 2.0 ports quantity: 2
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
PCI slots: 1
PCI Express x4 slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Other features
Weight: 845 g
Logistics data
Harmonized System (HS) code: 84733020
Warranty: Manufacturer warranty 24 months
