Περιγραφή
Processor
Compatible processor series: Intel(R) Core(TM) i3, Intel(R) Core(TM) i7, Intel(R) Core(TM) i9, Intel(R) Pentium(R) Gold, Intel(R) Core(TM) i5, Intel(R) Celeron(R)
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Motherboard chipset: Intel H610
Memory
Supported memory clock speeds: 5200, 4800, 5400, 5600, 5000
Maximum internal memory: 96 GB
Memory channels: Dual-channel
ECC ?ompatibility: Non-ECC
Unbuffered memory: Yes
Number of memory slots: 2
Supported memory clock speed (max): 5600 MHz
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Weight & dimensions
Depth: 195 mm
Width: 226 mm
Height: 36.5 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
Number of SATA III connectors: 4
Number of COM connectors: 1
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of chassis fan connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
TPM connector: Yes
USB 2.0 connectors: 2
12V power connector: Yes
Audio connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging data
Package weight: 680 g
Package depth: 223 mm
Package width: 246 mm
Package height: 50 mm
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Number of storage drives supported: 5
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 4
Rear panel I/O ports
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
PS/2 ports quantity: 2
HDMI ports quantity: 1
DisplayPorts quantity: 1
Microphone in: Yes
VGA (D-Sub) ports quantity: 1
Line-in: Yes
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Other features
Weight: 437 g
Warranty: warranty 36 months
