Περιγραφή
Processor
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Compatible processor series: Intel(R) Core(TM) i7, Intel(R) Core(TM) i9, Intel(R) Pentium(R) Gold, Intel(R) Core(TM) i3, Intel(R) Core(TM) i5, Intel(R) Celeron(R)
Maximum number of SMP processors: 1
Processor manufacturer: Intel
Graphics
Parallel processing technology support: Not supported
Features
Motherboard chipset: Intel B760
Windows operating systems supported: Windows 10 x64, Windows 11
Motherboard chipset family: Intel
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Memory
Maximum internal memory: 96 GB
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speed (max): 8000 MHz
Supported memory clock speeds: 6800, 8000 MHz, 4800, 7400, 5000, 6600, 5200, 7600, 7800, 6200, 5800, 5400, 6000, 5600, 7200, 7000, 6400
ECC ?ompatibility: Non-ECC
Unbuffered memory: Yes
Number of memory slots: 2
Weight & dimensions
Depth: 211 mm
Width: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
Internal I/O
CPU fan connector: Yes
TPM connector: Yes
S/PDIF out connector: Yes
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 1
12V power connector: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Number of COM connectors: 1
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 5, 0, 1, 10
Number of storage drives supported: 6
RAID support: Yes
Number of HDDs supported: 4
Rear panel I/O ports
S/PDIF out port: Yes
PS/2 ports quantity: 1
VGA (D-Sub) ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 2
Expansion slots
PCI Express x1 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Warranty: warranty 36 months
