Περιγραφή
Design
On/off switch: Yes
Cooling type: Active
Product colour: Black, White
Power
AC input voltage: 100 - 240 V
Power protection features: Overheating, Over power, Under voltage, Short circuit, Over voltage, Overcharge
Power Factor Correction (PFC) type: Active
Total power: 750 W
Combined power (+5Vsb): 12.5 W
Max output current (+5Vsb): 2.5 A
Combined power (+12V): 744 W
Combined power (+3.3V): 110 W
Max output current (+12V): 62 A
Max output current (+5V): 20 A
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
Combined power (+5V): 110 W
Efficiency: 92%
Combined power (-12V): 3.6 W
Weight & dimensions
Width: 150 mm
Weight: 1.47 kg
Depth: 150 mm
Height: 86 mm
Performance
Mean time between failures (MTBF): 120000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
ATX version: 3.0
Purpose: PC
Bearing technology: Ball bearing
Packaging data
Package weight: 2.88 kg
Package depth: 208 mm
Package width: 346 mm
Package type: Box
Package height: 144 mm
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 3
Cabling type: Fully-Modular
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 5
CPU power cable length: 65 cm
PCI Express power connectors (16-pin): 1
PCI Express power connectors (8-pin): 3
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 400 mm, 120
CPU P4 connector (4-pin): 2
Motherboard power cable length: 61 cm
Peripheral (Molex) power cable length: 400 mm, 150
Warranty: Gwarancja 96 miesiecy
