Περιγραφή
Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics
Parallel processing technology support: Not supported
Maximum resolution: 7680 x 4320 pixels
Features
Motherboard chipset: AMD B850
Motherboard form factor: ATX
Product colour: Black
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Power source type: ATX
Cooling type: Passive
Windows operating systems supported: Windows 11, Windows 10 x64
Memory
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 4
ECC ?ompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 9000 MHz
Weight & dimensions
Width: 305 mm
Height: 48 mm
Depth: 244 mm
Network
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
USB 2.0 connectors: 3
Thunderbolt headers: 1
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
S/PDIF out connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of chassis fan connectors: 4
Number of COM connectors: 1
EPS power connector (8-pin): Yes
Front panel connector: Yes
TPM connector: Yes
12V power connector: Yes
Peripheral (Molex) power connectors (4-pin): 1
RGB LED pin header: Yes
Chassis intrusion connector: Yes
Number of RGB LED pin headers: 3
Number of CPU fan connectors: 1
Number of water pump connectors: 1
Number of EPS power connectors (8-pin): 1
BIOS
BIOS flashback button: Yes
BIOS type: UEFI AMI
Packaging data
Package weight: 1.26 kg
Package depth: 273 mm
Package width: 353 mm
Package height: 68 mm
Packaging content
Cables included: SATA
Screws included: Yes
Antenna included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 1, 0, 5, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
Number of storage drives supported: 7
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Headphone outputs: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Line-in: Yes
Microphone in: Yes
WiFi-AP antenna jack: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
3rd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
Other features
Weight: 1.05 kg
Warranty: warranty 36 months
