Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Features
Motherboard chipset: AMD B850
Product colour: Black
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Audio chip: Realtek ALC1220
Memory
ECC ?ompatibility: ECC & Non-ECC
Memory channels: Dual-channel
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
LAN controller: Dragon RTL8125BG
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of EPS power connectors (8-pin): 1
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
USB 2.0 connectors: 2
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
TPM connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
M.2 standoff included: Yes
Antenna included: Yes
Cables included: SATA
Screws included: Yes
Storage controllers
RAID levels: 0, 10, 1
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-C, USB Type-A
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
WiFi-AP antenna jack: 2
Microphone in: Yes
Line-in: Yes
Headphone outputs: 3
Expansion slots
1st M.2 largest key size: 2580
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x8 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste.
Warranty: warranty 36 months
