Περιγραφή
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Features
Audio output channels: 7.1 channels
Product colour: Black
Motherboard chipset family: AMD
Audio chip: Realtek ALC4082
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: ATX
Motherboard chipset: AMD B850
Memory
Unbuffered memory: Yes
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, 802.11a, Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
LAN controller: Killer E3100G
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 3
EPS power connector (8-pin): Yes
TPM connector: Yes
12V power connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 2x2 connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of water pump connectors: 1
Number of EPS power connectors (8-pin): 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 1, 10, 0
Number of storage drives supported: 8
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-in: Yes
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
USB connector type: USB Type-A, USB Type-C
Headphone outputs: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
S/PDIF out port: Yes
HDMI version: 2.1
Microphone in: Yes
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 4.x) slots: 1
4th M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
3rd M.2 largest key size: 2280
4th M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste.
Warranty: warranty 36 months
