Περιγραφή
Processor
Processor socket: LGA 1700
Compatible processor series: Intel Core i7 13th Gen, Intel Core i9 14th Gen, Intel Core i3 14th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i3 12th Gen, Intel Core i9 13th Gen, Intel Core i3 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen
Processor manufacturer: Intel
Graphics
On-board graphics card model: Intel Iris Xe Graphics
HDCP version: 2.3
HDCP: Yes
Features
Motherboard chipset: Intel H610
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
Supported memory clock speeds: 5600, 4800
Maximum internal memory: 128 GB
Memory channels: Dual-channel
Unbuffered memory: Yes
Weight & dimensions
Depth: 193 mm
Width: 244 mm
Network
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek 8111H
Internal I/O
12V power connector: Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 1
USB 2.0 connectors: 1
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
TPM connector: Yes
Chassis intrusion connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
VGA (D-Sub) ports quantity: 1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
PS/2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 4
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Warranty: warranty 36 months
