Technical details
Compliance certificates: Federal Communications Commission (FCC), CE
Processor
Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Graphics
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Graphics card: AMD RDNA 2
On-board graphics card: Yes
HDCP version: 2.3
Graphics card family: AMD
High Dynamic Range (HDR) supported: Yes
Features
Motherboard chipset: AMD A620A
Product colour: Black
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Supported memory clock speeds: 8000 MHz
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
LAN controller: Dragon RTL8125BG
Antenna type: 2 x 2
Wi-Fi standards: 802.11n, 802.11b, 802.11 axe, 802.11g, 802.11a, 802.11ac, 802.11 ax
Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
Bluetooth: Yes
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet, Fast Ethernet, 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth version: 5.2
Internal I/O
Number of chassis fan connectors: 3
CPU fan connector: Yes
Number of SATA III connectors: 2
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
TPM connector: Yes
ATX Power connector (24-pin): Yes
12V power connector: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
RGB LED pin header: Yes
Number of water pump connectors: 1
BIOS
BIOS type: UEFI AMI
BIOS flashback button: Yes
Packaging content
Cables included: SATA
Storage controllers
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 1, 10, 0
Supported storage drive interfaces: M.2, NVMe, SATA III
Number of HDDs supported: 2
Rear panel I/O ports
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Antennas quantity: 2
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
Processor special features
Intel Extreme Memory Profile (XMP): Yes
AMD Extended Profiles for Overclocking (EXPO): Yes
Warranty: warranty 36 months
